What is Hover?

Hover is a development kit that lets you control your hardware projects in a whole new way.  Wave goodbye to physical buttons.  Hover detects hand movements in the air for touch-less interaction.  It also features five touch-sensitive regions for even more options.


As seen on



Just Hover

Hover can recognize up, down, left and right swipes up to 5 inches away.  Interact with your projects by just hovering your hand.



Or Simply, Touch

Hover has 5 capacitive pads and can recognize north, west, south, east, and center touch events.  Double taps are supported along with multiple touch events at the same time.


Easy to use


SCROLL DOWN

Easy to use


Technical Specs

  • Gesture Detection Range: up to 5 inches
  • Uses the MGC3130 as the gesture & touch controller

  • Gestures Supported: up, down, left, right (more coming soon)
  • Touch Features: up to 5 electrodes can be used for touch input.
  • Breadboard friendly

  • Works with any Arduino and Raspberry Pi
  • Uses I2C and 2 GPIOs to connect with Host
  • Compatible with 5V and 3.3V microcontrollers (on-board logic level shifting for I2C lines)

  • I2C slave @ address 0x42
  • Powered by 3.3V

  • Dimensions: 2.5 inches x 2.5 inches


Get Started

Get up and running in minutes with our guides.  Click one of the platforms below for hookup guides, software library, example code and easy to follow instructions.

Arduino

Arduino

Raspberry Pi

Raspberry Pi

Spark Core

Spark Core


Build cool things


SCROLL DOWN

Build cool things


Create rich interfaces

Create a gesture driven musical instrument by adding speakers, or create a touch-sensitive remote control.  There are many different possibilities for Hover.  Here are two examples.




Drum Machine

Swipe for cool audio clips and tap the board to play the drums.  See the entire set of instructions here.




Explore Google Earth

Browse Google Earth by hand gestures. Spin the globe with a simple hand swipe and tap to zoom in/out. See the entire set of instructions here..

*We're currently building more cool projects with Hover.  Stay tuned as we release more examples soon.


Get your own Hover


SCROLL DOWN

Get your own Hover


Order Hover

Buy direct from us or from a retailer below.



$39

Ships in 2-5 days

7 Pin Header populated.
Breadboard not included.
Ships worldwide.

Also available on Tindie and resellers below.
